| Types | Details |
|---|---|
|
Sizes |
From 300 mm Dia to 1500 mm Dia |
|
Useable Volume |
25 Ltrs to 900 Ltrs per batch |
|
Speed of Basket |
500 rpm 0.2000 rpm |
|
Suspension |
Inertia Plate with Anti Vibration
Mounts (4 Point Suspension) |
|
MOC |
Stainless Steel, Carbon Steel,
Hastelloy, Rubber Lined, Fluoro
Polymer Coating / Lining le. – Halar
(ECTEE), Teflon (PFA) |
|
Optional Features |
Fully Opening Outer Case/Lid for
better accessibility for cleaning and
validation purpose cGMP/Standard construction matching to various Types & custom requirements |
Technical Specifications
| Model | SS - 12 | SS- 24 | SS - 36 | SS - 48 | SS - 60 |
|---|---|---|---|---|---|
|
Basket dia. (mm) |
305 |
610 |
915 |
1220 |
1524 |
|
Basket Ht. (mm) |
200 |
300 |
458 |
458 |
510 |
|
Basket Speed (rpm) |
2000 |
1400 |
1025 |
850 |
700 |
|
Basket Max. |
12 |
70 |
250 |
325 |
500 |
|
Per.Load (Kg) |
|||||
|
Motor (H.P.) |
1 |
3 |
7.5 |
15 |
20 |
|
Volume underlip (Ltrs) |
12 |
50 |
200 |
295 |
450 |
|
Centrifugal Force (G) |
850 |
665 |
510 |
460 |
500 |
|
Filtration Area (Sq. Mtr.) |
0.161 |
0.59 |
1.25 |
1.91 |
2.39 |
|
Weight of Machine (Kg.) |
500 |
1100 |
2200 |
4000 |
6300 |
